特点介绍：

合模部分 CLAMPING UNIT
1、大拉杆内距,宽模板设计,模具适应范围广。
      Enlarged tie-bar distance, more molds can be used.
2、QT500-7球墨铸铁高刚性的模板设计,配合高安全系数的拉杆,整体提升合模结
      构的刚性及稳定性。
      The high rigidity formwork design of QT500-7 nodular cast
       iron, combined with the pull rod with high safety factor,
       improves the rigidity and stability of the clamping structure
       as a whole.
3、T型槽模板,方便模具的更换。
    “T ”groove templates is quite easy to change for mould.
4、可选配中心顶出强制复位功能。
      Optional center ejection forced reset function.
5、ZS1200及以上机型标配动板定位环安装位置。
     ZS1200 and above models are equipped with standard
     moving plate locating ring installation position.

注射部分 INJECTION UNIT

1、注射单元采用模组化的托板座设计,一线式双缸平衡注射装置,

      使螺杆在注塑过程中受力平均。
      Modular injection unit design with dragging plate structure, in-line type twin
      inject cylinders,working smoothly during injection process.
2、独特高混炼的注塑螺杆组件设计,具有高塑化效率和高耐磨性。
      Innovative screw design have good maxing effect, high plasticizing capacity.
3、料筒标配陶瓷加热圈，标配射台润滑手动油泵。
      The barrel is equipped with ceramic heating ring as standard, and the
      injection table lubricates the manual oil pump as standard.
4、可选配电动储料配置与开储同步功能。ZS500及以下机型可选配注射线性导轨。
      Optional electric storage configuration and synchronous function of opening
      and storing. ZS500 and below models can be equipped with injection linear
      guide rail.
5、汽配产品可选配顺序注射模块，无需再另加泵站，生产现场更加安全整洁。
      Auto parts products can be equipped with sequential injection module,
      without additional pumping station, and the production site is safer

      and cleaner.

液压部分 HYDRAULIC UNIT
1、高排量的液压系统设计,动力系统加大,注射速度比同类型产品提高
     15%,模循环周期缩短15%,全面提升注塑机表现,可满足高标准的成
     型要求。
       The hydraulic system design with high displacement, increase
     power system, injection speed and mold cycle time increase 15%
     than the same type products. comprehensively enhance the
     machine can meet high Standrad moulding requirements.
2、油路板分布在各执行元件位置,具有响应速度快,动态性能好。
       Hydraulic manifold are distributed around the execute components,
     having high response.
3、ZS220及以上机型标配数控背压阀及全系标配油温检测显示，ZS460及以下机型调模标配自锁马达。
     The model ZS220 and above comes standard with numerical control
      back pressure valve and oil temperature detection display, and the
      model ZS460 and below comes standard with self-locking motor.

电控部分 CONTROL SYSTEN
1、采用高端电脑主机，控制面板均为彩色大屏幕,时时监测生产进程,
     并显示各种故障诊断。
     Use high-end computer mainframe control panel with color
     screen to monitor the production process from time to time and
     Displays various troubleshooting.
2、采用新型伺服驱动及电机，提高系统响应速度及精度。
     New servo drive and motor are adopted to improve the response
     speed and accuracy of the system.
3、标配机械手、针阀接线端子排。
     Standard manipulator, needle valve terminal block.
